OK 63.30
General description:
EN 1600 E 19 12 3 L R 12
AWS A-5.4 E316L-17
Rutil-acid-coated,
low-carbon (ELC) welding electrode for welding 18Cr12Ni3Mo (AISI 316L)
alloy austenitic corrosion-resistant steels. It is also
suitable for stabilized materials with the same composition, except when
the total creep resistance of the raw material is a requirement.
Advantages:
The OK 63.30 has very good arc-arc and arc re-ignition properties, which creates a very attractive seam surface. Slag self-shedding. The coating is LMA (Low Moisture Absorption), ie low absorbent.
| Electrode parameters | Package | ||
| Diameter (mm) | Lenght (mm) | Amperage (A) | Weight/pack (kg) |
| 2,0 | 300 | 50-80 | 2,0 |
| 2,5 | 350 | 60-100 | 1,0 |
| 2,5 | 350 | 60-100 | 2,5 |
| 2,5 | 350 | 60-100 | 5,0 |
| 3,2 | 350 | 80-140 | 5,0 |
| 2,0 | 300 | 50-80 | Hobby (19db) |
| 2,5 | 350 | 60-100 | Hobby (15db) |
| 3,2 | 350 | 80-140 | Hobby (11db) |
